Equipment and Upgrades

  • Engine Volvo Penta D2-55
  • S-Drive S130 with 3-blade folding propeller. Seal replaced (2024)
  • Main sail with 5 full battens and 3 reefs. North Sails 3Di Ocean (2021)
  • UK Sailmakers 130% genoa on below deck furler. Radial laminate (2024)
  • North Sails 130% genoa. 3Di Ocean (2021).
  • QSails Genoa 3. Spare sail. Dacron/Dyneema (2021).
  • Gennaker. Elvström radial woven on Seldén GX 15 furler (2014)
  • New Dyform standing rigging (2022)
  • Completely new rudder (2024)
  • Max Power retractable bow thruster
  • Spade 25 kg main bow anchor with 80 m of 10 mm diameter chain and Mantus swivel (2019)
  • Quick electric bow windlass. 1400W
  • Bruce 15 kg stern anchor on Engbo electric windlass
  • Fortress FX-23 spare anchor (2022)
  • Victron LiFeP04 (lithium phosphate) service batteries. 3 x 200 Ah (2020)
  • Optima 55 Ah Deep Cylcle AGM starter battery (2023)
  • Victron 100 A Buck-Boost DC/DC Converter to regulate 115 A alternator (2020)
  • Victron Multiplus 3000 W inverter/charger (2020)
  • 6 x 100 W solar panels with Victron MPPT 150/60 for service batteries (2020)
  • 3 x 110 W solar panels with Victron MPPT 100/50 for service batteries (2024)
  • 55 W solar panel for starter battery (2024)
  • Victron Cerbo electric control and monitoring panel (2024)
  • Rainman 220 V watermaker. 140 l/hr capacity (2021)
  • 200 l diesel tank under aft starboard cabin
  • 205 l fresh water tank under aft port cabin and 175 l under front cabin
  • 20 l hot water boiler
  • 50 l holding tank
  • New Groco bronze thru hull fittings and seacocks (2022)
  • Ebersprächer D.5 diesel heater
  • Ecoflow Wave 2 air conditioning (2025)
  • Davits for tender and outboard engine on stainless steel arch (2020)
  • AB Inflatables AL 9.5 Lammina tender. Hypalon tubes and aluminium hull (2021)
  • Seatec inflatable SUP. 3.3 m (2021)
  • Tohatsu M9.8B outboard (2023)
  • Honda BF 6 hp outboard (2021)
  • Raymarine EV-400 autopilot with linear drive directly to quadrant (2024)
  • Raymarine SPX-30 autopilot with linear drive as secondary unit
  • Raymarine ST60 wind, speed and depth instruments
  • Raymarine Axiom 2 Pro 9 inch chart plotter at helm station (2024)
  • Raymarine Axiom 9 inch chart plotter at nav station (2024)
  • Ocean Signal ATB1 Class B AIS. Receiving and transmitting (2024)
  • Raymarine Quantum 2 Doppler radar (2024)
  • Raymarine VHF DSC 54E
  • Starlink satellite communication antenna and router (2024)
  • IridiumGo satellite communication router (2020)
  • Plastimo 6-man life raft in cannister. ISO 9650-1A Ocean (2021, serviced and repacked 2024)
  • Ocean Signal Epirb1 (2021)
  • Two Ocean Signal MOB1 Personal Location Beacons (2021)
  • Fusion MS-RN 70N Stereo (2022)
  • Panasonic 32 inch TV (2024)
  • New teak deck in cockpit and on coach roof (2020)
  • Honda EU22i inverter/generator (2021)
  • Dometic CFX3 45 Freezer (2021)
  • Refrigerator with Danfoss BD50F Compressor
  • ENO gas cooker 2 hobs and oven. Self-levelling
  • 2000 W Electric induction cooker
Schematic of 12 DC system
Schematic drawing of electronic navigation system
